Pos Printers

POS RXPO-XR1

Retail printer delivering high productivity across all operating system environments

Technical Sheet

Division	Content
Printing System	Direct Thermal auto load
Cutting System	Full cut or partial cut(through command)
Media	Thermal Rolls: Paper, Die cut continuous Label
Paper width	79.5 ± 0.5mm (MAX)
Printing width	76 mm
Roll Diameter	80 mm
TPH life	100km (Max)
Paper thickness	0.06~0.08 ㎛
Printer Resolution	203dpi
Characters/line	ASCII 9X17, 12X24, GB18030 24X24
Resolution	203 dpi, 8 dots/mm
Printing speed	250mm/s (MAX)
Dimensions (W x L x H mm)	195 x 145 x 143.3 (L x W x H)
Cutter life	1,000,000 cuts

Accssories
- 24V Power adaptor(with an AC power cord)
- 9pin female to female serial cable
- USB A-B Cable
옵션 장착 사진
Download
- Manual
  - 4-PO-1-MA_RXPO-XR1 Technical Manual.pdf ()
- Spec Sheet
  - 4-PO-1-SP_RXPO-XR1 SPECSHEET Ver1.0_250902.pdf ()
- SDK (Window)
  - 4-PO-1-SDKWIN_RXPO-XR1_driver, SDK.zip ()
- SDK (Android)
  - 4-PO-1-SDKAND_RXPO-XR1_driver, SDK.zip ()
- Driver (Window)
  - 4-PO-1-DRWIN_RXPO-XR1_driver, SDK.zip ()
- Utility (Firmware update tool)
  - 4-PO-1-FW_OPOS_POSPrinterSO V3.8.zip ()
