Kiosk Printers
3inch
RX831-H120PRM2
80 mm ticket / receipt printer with presenter function
-
Technical Sheet
상품 정보 고시
Division Content Printing System Direct Thermal auto load Cutting System Auto cutter Presenter Available as an option Bezel Available as an option Media Thermal Rolls: Paper, Die cut continuous Label Paper width 80 mm Printing width 72 mm Roll Diameter 120 mm Roll Length 185 m Paper thickness 0.05 to 0.12 mm Dots/line 576 Characters/line 24, 48, 64 Resolution 203 dpi, 8 dots/mm Printing speed Up to 200 mm/sec Dimensions (W x L x H mm) 130 x 203.3 x107.9 Weight (without paper) 780g Interfaces Serial : USB & RS-232C Sensors Paper presence, Black mark, Near paper end, Paper end, Printer head open, Cutter home Voltage 24VDC - 110/240VAC adapter available Current 1.7A (mean) 17.6A (peak) Print head life 150km Cutter life 1 million cuts Operating temperature 5~55°C -
Accssories
-
24V Power adaptor(with an AC power cord) -
9pin female to female serial cable -
USB A-B Cable
-
